Introduction
Organization
network requirements, and grounding requirements. Explains how to install both the Base and
the Expansion Cabinets. Instructions are also provided on how to remove and replace cabinets
on installed systems.
Chapter 6 – DK424 T1 provides information on T1/DS-1 interfacing for the DK424.
T1/DS-1 interfacing is not available for the DK14 and DK40i.
Chapter 7 – DK Universal Slot PCBs provides procedures for Strata DK40i/DK424 system
Printed Circuit Boards (PCBs) for installation into universal slots. It includes installation
instructions, optional configuration information, and wiring and programming considerations
for each PCB.
Note
Chapter 8 – DK Universal Slot PCB Wiring contains point-to-point wiring diagrams for
connection of telephones, lines, peripheral equipment, and power supplies to the Strata DK
systems.
Note
Chapter 9 – Station Apparatus provides instructions on how to connect telephones to the
Strata DK systems and how to configure and upgrade them for optional features. Procedures
for installing direct station selection consoles, PC and conventional attendant consoles, and
door phones also appear.
Chapter 10 – Peripheral Installation provides connection procedures for optional peripheral
equipment to Strata DK systems. The instructions for each option include hardware
requirements, PCB configuration, interconnection/wiring requirements, and programming
considerations.
Chapter 11 – DK424 ACD Installation includes installation instructions for Automatic Call
Distribution (ACD) and Management Information System (MIS) for the Strata DK424
(applies to all common control processors except the RCTUA). Includes installation
instructions for Call Center Viewer. ACD and MIS is not available to the DK14 and DK40i.
Chapter 12 – Fault Finding for troubleshooting and fixing problems.
Chapter 13 – Computer Telephony Integration (CTI) contains CTI, TAPI, and System
Open Architecture Interface information. CTI application notes can be inserted here.
Chapter 14 – ISDN contains an overview of the ISDN hardware with specific information on
the ISDN Primary Rate Interface (PRI) and Basic Rate Interfaces (BRI). It includes
instructions for installation, hardware requirements, wiring requirements, and some
programming considerations.
Chapter 15 – Hospitality Management Information System (HMIS) gives you information
about HMIS, including installation, the Setup Utility, maintaining the HMIS databases and
software, and troubleshooting.
Chapter 16 – Strata AirLink Systems gives information about the external and integrated
wireless systems (BSIA and RWIU), including system components, installation of hardware
and software, and troubleshooting.
Glossary/Index
xvi
PCBs that cannot be installed into universal slots can be found in the installation chapter
for the system (e.g., Chapter 3 – DK40i Installation).
Wiring diagrams for PCBs that cannot be installed into universal slots can be found in the
installation chapter for the system (e.g., Chapter 3 – DK40i Installation).
Strata DK I&M 5/99
