DK424 RCIU1/RCIS or RCIU2/RCIS Installation

1. Install the RCIS onto the RCIU1 or RCIU2 as required (see
2. Install the RCIU1/RCIS or RCIU2/RCIS into the appropriate cabinet slot. The circuit modular
jack numbering and the tip/ring cross connect wiring of RCIU1/RCIS or RCIU2/RCIS to
RCOU, PCOU, or RGLU is shown in
Note It is not necessary to install the RCIU1, RCIU2, RCIU1/RCIS, or RCIU2/RCIS PCBs in
the same cabinet as their associated CO lines or in slots adjacent to the lines.

RCIU1, RCIU2, RCIS Programming

Program 03: Program each RCIU1, RCIU2, RCIU1/RCIS or RCIU2/RCIS (four or eight Caller ID
circuit) slot with code 81.
Note RCIU1/RCIS or RCIU2/RCIS caller ID circuits are numbered automatically in numerical
order starting with the RCIU1/RCIS or RCIU2/RCIS installed in the lowest slot number.
Slots with code 81 increment the Caller ID circuit numbers by eight circuits even if RCIS
is not installed on the RCIU1 or RCIU2.
Program *50: Assigns CO lines that will receive Caller ID to an associated RCIU1/RCIS or
RCIU2/RCIS Caller ID circuit number. This assignment is flexible, i.e., any RCOU, PCOU,
RGLU Caller ID CO line can be assigned to any RCIU1, RCIU2 or RCIS caller ID circuit number.
After assigning CO lines to caller ID circuits, turn system power OFF for approximately
Note
five seconds and then back ON or run Program 91-2 to activate Program *50 assignments.
Program *51: Sets the Caller ID (CLID)/Automatic Dialed Number Identification (ANI) memory
allocation for the appropriate stations. This memory is used to save CLID/ANI telephone numbers
for calls that are received but not answered (abandoned calls). CLID/ANI numbers are not saved in
station memory if they are answered. Stations can be allocated with memory to save up to 100
numbers in 10-number increments.
The total memory allocated to all stations in a system is:
RCTUE/F = 2000 numbers
RCTUC/D = 1000 numbers
RCTUBA/BB = 400 numbers
RCTUA and DK40i = 200 numbers
When a CO line rings multiple stations, a station must be the owner of the Caller ID or
Note
ANI CO line to be able to save abandoned call (Caller ID and/or ANI) telephone numbers.
(See Program *52.)
Program *52: Assigns stations as owners of Caller ID CO lines. These stations will store the Caller
ID telephone numbers received on abandoned (not answered) calls for the lines which they own.
Typically all common CO lines are assigned to one designated telephone or attendant console and
private lines are assigned to individual private line telephones.
7-24
Figures 7-11
Figure 8-25 on Page 8-26.
and 7-13).
Strata DK I&M 5/99
