Sam4s ER-5200 Service Manual page 98

10 PCB Layout and Parts List
10-6 Display Layout
10-6-2 ER-5200 Rear Display (VFD 10Digit)
No. Parts No.
- JK92-01231A
- JK39-40002A
- JK07-00005A
- 3711-002812
- JK73-10207A
- JK94-00053A
- JC39-40511A
- JK41-10548B
10-6-3 ER-5200M Rear Display (VFD 10Digit)
No Part -No
- JK92-00970B
- 3711-004109
- JK07-00005A
- JK39-40606A
- JK73-10207A
- 1003-001381
- JK69-90902A
- JK94-00028A
- 0402-000129
- 0402-000208
- JK41-10547A
- 2202-000579
- JC39-40511A
10-12
Downloaded from www.Manualslib.com
Description / Specification
PBA SUB-TURRET:ER-5100/5200,STD
CBF HARNESS:ER-220N,-,UL1061,400MM,BLK/R
DISPLAY VFD-DC10G:FUTABA,10-LT-50GK
CONNECTOR-HEADER:BOX,11P,1R,2mm,STRAIGHT
RPR-PAD:ER-220N,SPONGE,-,BLK
PHANTOM AU JK92-01231A
CBF HARNESS:ML-80,JUMPER,AWG22,52mm,SILV
PCB-TURRET:ER-5100/5200,FR-1,1L,T1.6
Description/Specification
PBA SUB-TURRET:ER-450,WORLD,BASIC
WAFER;BOX-HEADER,1R,8P,2.5mm,STRAIGHT
DISPLAY VFD-DC10G:FUTABA,10-LT-50GK
HARNESS-TURRET:ER-450,8P,500mm,TUBE
RPR-PAD:ER-220N,SPONGE,-,BLK
IC-VFD:HV5812P,DIP,28P,540MIL,-,-,ST,PLA
PACKING-VINYL:PET,#2126,30X100000XT0.05
PHANTOM AU JK92-00968A
DIODE-RECTIFIER:1N4003,200V,1A,DO-41,TP
DIODE-RECTIFIER:EK-04,40V,1.5A,DO-41
PCB-TURRET:ER-650/5200,FR-1,1L,T1.6
C-CERAMIC,MLC-AXIAL:100nF,+80-20%,50V,Z5
CBF HARNESS:ML-80,JUMPER,AWG22,52mm,SILV
manuals search engine
Q`ty Design- Location
1
REAR DISPLAY ASSY
1 DISPLAY TO MAIN
1 FUTABA VFD/10 DIGIT
2 CN1,CN2
2 PAD
1 AUTO
5 JP1,JP2,JP3,JP4,JP5,JP6
1 FUTABA VFD/10 DIGIT
Q'TY Design Location
1
1 CN1
1 V1
1 TURR TO MAIN
2 T5.0
1 U1
0.002 DIGITRON
1
1 D1
1 D2
1
2 C1,C2
9 J1 ~ J9
Serviceable Remark
Y
Y
Y
Y
Y
N
Y
Y
Serviceable Remarks
WHITE
TUBE
SAM4S ER-5200 Series
