8 Troubleshooting
8-2 System Problem
System Problem
8-2
Downloaded from www.Manualslib.com
Reset Signal N
Ok?
Y
Power Fail N
Signal Ok?
Y
CPU N
Ok?
Y
Program N
Ok?
Y
SRAM Ok? N
Y
RTC Ok? N
Y
End
manuals search engine
1. Check the IC M51953B(U13)
2. Check the 74HC14(U17).
3. Check the RST Pattern on PCB.
1. Check the LM393(U22)
2. Check the Power (+24V,+5V)
3. Check the related Circuit and Pattern on PWB
1. Check the Clock (14.7456MHz)
2. Check the Power of CPU VCC Pin (+5V)
3. Check the mounted state of CPU pin whether the pin is
open or short
1. Check the nCS, nRD signal of Flash ROM
2. Check the Addr/Data line Pattern whether it is short.
3. Download the PGM File in Flash ROM through RS-232
Cable.
4. Replace the Flash ROM
1. Check the nCS, nRD, nWR signal of SRAM
2. Check the VBT(Battery Volt.).
3. Check the Decoder IC 74HC138 (U24).
4. Replace the SRAM.
1. Check the nCS, nRD, nWR signal of RTC
2. Check the VBT(Battery Volt.).
3. Check the Decoder IC 74HC138 (U24).
4. Check the RTC Clock 32.768KHz
5. Replace the RTC(RF5C15)
