Sam4s ER-5200 Service Manual page 10

2-3 Thermal Printer Specifications
2-3-1 Printer Specification
Model
Print Method
Printing Format
Printing Speed
Printing Direction
Paper Feeding
Power Supply Volt
Printer Head
Line Feed Motor
Sensor
Auto Cutter
Reliability
Dimension (mm)
Weight
SAM4S ER-5200 Series
Downloaded from www.Manualslib.com
Item
Total number of dots
Dot Pitch
Feeding Method
Minimum Feed Pitch
Feeding Speed
Power Voltage
Circuit input Voltage
Heat Element Density
Total Head Elements
Available Printing Width
Heat element typical Ω
Head Temperature
Paper-End Sensor
Printer Cover Open Sensor
Model
Life
MCBF
Table2-2 Thermal Printer Specifications
manuals search engine
Description
• STM-210
• Thermal Line Printing
• 384 Dots / I Line
• Vertical
: 0.125 mm
• Horizontal
: 0.125 mm
• 50 mm/Sec ( At 8.5V of Motor Voltage)
• Unidirectional friction feed
• Friction Feed
• 0.0625 mm
• 50 mm/Sec (At 8.5V of Motor Voltage)
• 8V / 8.5V (Recommend)
• 5V
• 8 Dots/mm (0.125 mm/Dot)
• 384 Dots/Dot Line
• 48 mm
• 176 Ω ±4%
• 4-Phase Bi-Polar Stepping Motor
• Thermistor
• Reflecting Photo Sensor
• Micro Switch
• SAC-60 (Guillotine Type)
• 15,000,000 Lines
• 37,000,000 Line
• 82.5 (W) ×147.3 (D) ×101.4 (H)
• Approx. 365 g
2 Product Specifications
Remark
Shin Heung Precision
Head/Motor
Head Control/Sensor
Shin Heung Precision
2-3
