Sam4s ER-5200 Service Manual page 92

10 PCB Layout and Parts List
10-2 Power PCB Layout
10-2-2 Parts List
No. Parts No.
0502-000288
1203-000391
2401-001312
JK27-60100D
JK96-01082B
0502-000234
6002-000175
6203-000107
JK94-00050A
0402-000129
0403-000161
2001-000027
2001-000042
2001-000055
2001-000065
2001-000561
2001-000588
2001-000855
2004-000284
0501-000294
0501-000399
2201-000119
2201-000138
2201-000162
2401-000032
2401-001363
3301-000344
3602-000001
JC39-40511A
JK41-10545A
10-6
Downloaded from www.Manualslib.com
Description / Specification
TR-POWER:KSD288,NPN,25W,TO-220,-,120-24
IC-DC/DC CONVERTER:34063,DIP,8P,250MIL,P
C-AL:4700uF,20%,50V,GP,BK,22x40,10
COIL FILTER:ER-350,140 UH,-,-
ELA ETC-HEAT SINK(5200):1010:ER-5200,BAS
TR-POWER:KSA1010Y,PNP,40W,TO-220,TP,100
SCREW-TAPPING:PWH,+,2,M3,L8,ZPC(YEL)
HEAT SINK:NONE,T2,W17,L22,H45,DEGRE,AL60
PHANTOM AU ER-5500 POWER BOARD
DIODE-RECTIFIER:1N4003,200V,1A,DO-41,TP
DIODE-ZENER:1N4751,5%,1000MW,DO-41,TP
R-CARBON:100OHM,5%,1/4W,AA,TP,2.4X6.4MM
R-CARBON:1KOHM,5%,1/4W,AA,TP,2.4X6.4MM
R-CARBON:4.7KOHM,5%,1/4W,AA,TP,2.4X6.4MM
R-CARBON:10KOHM,5%,1/4W,AA,TP,2.4X6.4MM
R-CARBON:27KOHM,5%,1/4W,AA,TP,2.4X6.4MM
R-CARBON:3.3KOHM,5%,1/4W,AA,TP,2.4X6.4MM
R-CARBON:560OHM,5%,1/4W,AA,TP,2.4X6.4MM
R-METAL:12Kohm,1%,1/4W,AA,TP,2.4x6.4mm
TR-SMALL SIGNAL:KSA708-Y,PNP,800mW,TO-92
TR-SMALL SIGNAL:KSC945-G,NPN,250mW,TO-92
C-CERAMIC,DISC:100nF,+80-20%,50V,Y5V,TP,
C-CERAMIC,DISC:100pF,10%,50V,Y5P,TP,4.0X
C-CERAMIC,DISC:10nF,+80-20%,50V,Y5V,TP,7
C-AL:100uF,20%,50V,GP,TP,8x12,5mm
C-AL:470uF,20%,16V,GP,TP,10x12.5,5
CORE-FERRITE BEAD:AA,-,3.5x0.6x6.5mm,-,-
FUSE-CLIP:-,-,30mohm
CBF HARNESS:ML-80,JUMPER,AWG22,52mm,SILV
PCB-POWER:ER-52/5500,FR-1,1L,T1.6mm,117X
manuals search engine
Q`ty Design- Location
2 Q3,Q6
2 U1,U2
2 C7,C8
2 L8,L10
1
2 Q9,Q10
2 HS1,HS2
2 HS1,HS2
1
5 D1,D2,D3,D4,D5
1 ZD1
1 R1
6 R4,R5,R9,R10,R22,R23
2 R2,R27
R3,R6,R7,R8,R11,R12,R14,
10
R15,R16,R17
1 R29
2 R24,R25
2 R21,R26
1 R28
3 Q1,Q2,Q11
4 Q4,Q5,Q7,Q8
C3,C4,C5,C6,C11,C12,C17,
8
C18
2 C15,C16
2 C1,C2
2 C9,C10
2 C13,C14
8 L1,L2,L3,L4,L5,L6,L7,L9
2 FU1
9 J1,J2,J3,J4,J5,J6,J7,J8,J9
1 POWER PCB
SAM4S ER-5200 Series
Serviceable Remark
Y
Y
Y
Y
N
Y
Y
Y
N
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
