Sam4s ER-5200 Service Manual page 13

2 Product Specifications
2-3 Thermal Printer Specifications
2-3-6 Printer Connector
2-6
Downloaded from www.Manualslib.com
Pin No.
1 Lever Sensor
2 GND
Table2-6 Printer Cover Open Switch Pin Assignment
Pin No.
1 Phase B
2 Phase B-
3 Phase A
4 Phase A-
Table2-7 Printer Line Feed (Paper Feed) Motor Pin Assignment
Pin No.
1 Paper End Sensor LED Current Limit Signal
2 Paper End Sensor Input Signal
3 VCC
Table2-8 Printer Paper End Sensor Pin Assignment
Pin No.
1 VCC
2 Paper Near Sensor Input Signal
3 Paper Near Sensor LED Current Limit Signal
Table2-9 Printer Near End Sensor Pin Assignment
Pin No.
1 VCC
2 Black Mark Sensor Input Signal
3 Black Mark Sensor LED Current Limit Signal
Table2-10 Black Mark Sensor Pin Assignment
Pin No.
1 Auto Cut Motor DC Out#2
2 Auto Cut Motor DC Out#1
3 Auto Cut Sensor Input Signal
4 GND
Table2-11 Auto Cut Motor & Sensor Pin Assignment
manuals search engine
Signal Description
Signal Description
Signal Description
Signal Description
Signal Description
Signal Description
Remark
CN8
Remark
CN3
Remark
CN4
Remark
CN5
Remark
CN6
(Printer Discon Check)
Remark
CN7
SAM4S ER-5200 Series
