7-7 Thermal Printer Circuit
CLK
DATA
LATCH
STB1,2,3
STB4,5,6
CLK
DATA
LATCH
STROBE#1
SAM4S ER-5200 Series
Downloaded from
www.Manualslib.com
384 Bits
Printing(1~192)
DATA LATCH
STB On Time
(1~192)
Figure 7-15 Thermal Printer Timing Waveform
manuals search engine
384 Bits
Printing(193~384)
CLK
384 BITs
DATA
LATCH
STROBE#1
7 Special Circuit Description
384 Bits
DATA LATCH
STB On Time
7-11
