Sam4s ER-5200 Service Manual page 91

10-2 Power PCB Layout
10-2-1 Component and Solder Side View
10-2-2 Parts List
No. Parts No.
JK92-01227A
3711-000183
3711-000034
3711-000242
3711-000961
3711-003969
3601-000261
JK39-40556A
JK39-40555A
0402-000119
0402-000168
0402-000290
SAM4S ER-5200 Series
Downloaded from www.Manualslib.com
Description / Specification
PBA SUB-POWER:ER-5200/5500,STD
CONNECTOR-HEADER:1WALL,2P,1R,3.96mm,STRA
CONNECTOR-HEADER:BOX,2P,1R,2.5mm,STRAIGH
CONNECTOR-HEADER:1WALL,4P,1R,3.96mm,STRA
CONNECTOR-HEADER:BOX,4P,1R,2.5mm,STRAIGH
CONNECTOR-HEADER:BOX,2P,1R,2.5mm,STRAIGH
FUSE-CARTRIDGE:250V,3.15A,TIME-LAG,GLASS
CBF HARNESS-SUB:ER-52/5500,6P,80mm
CBF HARNESS-POWER:ER-52/5500,10P,80mm,AW
DIODE-BRIDGE:W02G,200V,1.5A,-,-
DIODE-RECTIFIER:1N5822,40V,3A,DO-201AD,T
DIODE-BRIDGE:KBU6B,100V,6A,-,BK
manuals search engine
10 PCB Layout and Parts List
Q`ty Design- Location Serviceable
1 ASSY
1 CN4
1 CN3
1 CN2
1 CN1
1 CN5
1 FU1
1 CN6
1 CN7
1 BD1
2 D6,D7
1 BD2
Remark
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
10-5
