6 Reference Information
6-1 Semiconductor Base Diagram
6-1-4 Other ICs
Figure 6-15 KA393
6-1-5 TR , Diode
TO-220
1
1.Base 2.Collector 3.Emitter
[KSA1010-Y]
SOT-23
1
2
1:B ase 2:E mitter 3:C ollector
[KSA1182-Y]
6-8
Downloaded from www.Manualslib.com
Collector
Capacitor
TO-220
1
1.Base 2.Collector 3.Emitter
[KSD288-Y]
SOT-23
3 3
1
2
1:B ase 2:E mitter 3:C ollector
[MMBT2222A]
Figure 6-18 Transistor & Diode
manuals search engine
PIN CONNECTIONS
Switch Driver
8
1
Collector
Switch
7
2 I Sense
pk
Emitter
Timing
6
3 V
CC
Comparator
4 5
Gnd
Inverting
Input
(T o p V iew)
Figure 6-16 KA34063
TO-92
1
1. Emitter 2. Base 3. Collector
[KSA708-Y]
SOT-23
1
2
1:A node 2:N.C
[MMBD6050]
5 OUTPUT
M
4
DELAY CAPACOTOR
5
1
3
9 GND
5
3
2 N.C
1
SUPPLY VOLTAGE
Figure 6-17 M51953
TO-92
1
1. Emitter 2. Base 3. Collector
[KSC945-G]
3
3:C athode
