Chapter 3 Switch Installation

Installing the Switch

Rack Mounting
Warning
78-15136-03
This section describes these installation procedures:
Rack Mounting, page 3-19
•
Wall Mounting, page 3-33
•
Table or Shelf Mounting, page 3-37
•
To prevent bodily injury when mounting or servicing this unit in a rack, you
must take special precautions to ensure that the system remains stable. The
following guidelines are provided to ensure your safety:
• This unit should be mounted at the bottom of the rack if it is the only unit in the rack.
• When mounting this unit in a partially filled rack, load the rack from the bottom to the
top with the heaviest component at the bottom of the rack.
• If the rack is provided with stabilizing devices, install the stabilizers before mounting
or servicing the unit in the rack.
To install the switch in a 19-inch or 24-inch rack (24-inch racks require optional
mounting hardware), follow the instructions described in these procedures:
Removing Screws from the Switch, page 3-20
•
• Attaching Brackets to the Catalyst 3750G-24TS Switch, page 3-21
Attaching Brackets to the Catalyst 3750-24TS, 3750G-24T, 3750G-12S,
•
3750-24PS, 3750-48PS, 3750G-16TD, and 3750-48TS Switches, page 3-26
Mounting the Switch in a Rack, page 3-29
•
Attaching the Cable Guide, page 3-31
•
Catalyst 3750 Switch Hardware Installation Guide
Installing the Switch
3-19
