Rebound Damping Adjustment
civk
1.
Rebound damping adjuster (red)
2.
Fork top cap
The
rebound
damping
located at the top of the right hand fork.
To change the rebound damping force,
rotate the (red) adjuster clockwise to in-
crease, or counterclockwise to decrease.
Note:
•
The setting is measured as the
number of adjuster clicks counter-
clockwise from the fully clockwise
(closed) position.
Front Suspension Setting Chart
The Solo (Normal) suspension settings
provide a comfortable ride and good
handling characteristics for general, solo
riding.
The
following
suggested
settings
suspension.
1
2
adjuster
is
chart
shows
for
the
front
Loading
Compres-
sion
Damping¹
(left hand
fork)
Solo (Normal)
17
Solo (Comfort)
25
Solo (Sport)
4
Solo (Off-Road) 25
Solo (with
13
Loaded
Luggage Items)
Rider and
12
Passenger
Rider and
11
Passenger
(with Loaded
Luggage Items)
¹ Number of clicks counterclockwise
from
the
fully
position noting that the first stop (click)
is counted as 1.
Note:
•
This chart is only a guide. Setting
requirements may vary for rider
weight and personal preferences.
See
the
following
information regarding suspension
adjustment.
Maintenance
Rebound
Damping¹
(right hand
fork)
17
25
4
25
13
12
11
clockwise
(closed)
pages
for
