Ordering Information - Analog Devices EVAL-ADAU1466Z User Manual

EVAL-ADAU1466Z

ORDERING INFORMATION

BILL OF MATERIALS
Table 8.
Qty. Designator
42
C1, C6 to C10, C13, C14,
C16 to C18, C20, C22,
C23, C25 to C31, C34,
C36, C42, C43, C48,
C50, C55, C58, C70,
C71, C80, C87, C88,
C91, C93, C104, C109,
C112, C122 to C124
4 C11, C12, C15, C19
2 C125, C126
26
C21, C24, C47, C53,
C56, C59, C61, C64,
C66, C67, C75, C78,
C81, C82, C86, C89,
C94, C98, C101, C102,
C106, C111, C113,
C115, C116, C121
3 C2, C3, C45
1 C32
2 C35, C39
2 C37, C38
1 C4
1 C40
2 C41, C44
8 C46, C52, C65, C77,
C85, C100, C105, C120
8
C49, C51, C69, C74,
C90, C96, C108, C118
2 C5, C33
4 C54, C72, C92, C107
8 C57, C68, C76, C84,
C95, C103, C114, C119
8 C60, C62, C79, C83,
C97, C99, C110, C117
2 C63, C73
7 D1 to D7
1 J1
2 J2, J3
1 J4
6 J5 to J10
1 L1
2 L2, L3
1 Q1
1 R12
User Guide
Description
Multilayer ceramic capacitor, 0.10 μF, 16 V, X7R,
0402
Multilayer ceramic capacitor, 10 nF, 25 V, X7R, 0402
Aluminum electrolytic capacitor, 47 μF, 105°C,
SMD_D
Multilayer ceramic capacitor, 10 μF, 10 V, X7R, 0805
Aluminum, electrolytic capacitor, 100 μF, 105°C,
SMD_E
Multilayer ceramic capacitor, 390 pF, 50 V, NP0,
0402
Multilayer ceramic capacitor, 1.0 μF, 16 V, X7R, 0603
Aluminum electrolytic capacitor, 10 μF, 105°C,
SMD_B
Multilayer ceramic capacitor, 150 pF, 50 V, NP0,
0402
Multilayer ceramic capacitor, 10 μF, 25 V, X7R, 1210
Multilayer ceramic capacitor, 0.10 μF, 35 V, X7R,
0402
Multilayer ceramic capacitor, 1.8 nF, 25 V, NP0, 0402
Multilayer ceramic capacitor, 180 pF, 50 V, NP0,
0402
Multilayer ceramic capacitor, 5.6 nF 25 V, NP0, 0402
Multilayer ceramic capacitor, 330 pF, 50 V, NP0,
0402
Multilayer ceramic capacitor, 1.0 nF, 50 V, NP0, 0402
Multilayer ceramic capacitor, 100 pF, 50 V, NP0,
0402
Multilayer ceramic capacitor, 22 pF, 50 V, NP0, 0402
LED, green, 571 nm, 2 V, 3 mcd, 0603
Header, 2 × 5, 0.1 inch, shrouded, polarized
Header, 2 × 3, 0.1 inch, unshrouded
Jack, power connector, 2.0 mm ID, 5.5 mm, outside
diameter, through hole, right angle
Jack, 3.5 mm headphone, stereo, right angle, SMD
Chip ferrite bead, 600 Ω, at100 MHz, 500 mA, 0805
Chip inductor, 47 μH, 140 mA, 3.25 Ω, 0603
Transistor, BJT, PNP, 60 V, 5 A, TO-252AA
Chip resistor, 562 Ω, 1%, 63 mW, thick film, 0402
Part Number
GRM155R71C104KA88D
GRM155R71E103JA01J
EEE-FC1C470P
GRM21BR71A106KE51L
EEE-FC1C101P
GRM1555C1H391JA01D
GRM188R71C105KA12D
EEE-FC1C100R
GRM1555C1H151JA01D
GCM32ER71E106KA57L
CGA2B3X7R1V104K050BB
C0402C182J3GACTU
GRM1555C1H181GA01D
GRM155R71E562KA01D
GRM1555C1H331JA01D
GRM1555C1H102JA01D
GRM1555C1H101JZ01D
GRM1555C1H220JZ01D
LTST-C191KGKT
N2510-6002RB
PBC06DAAN, or cut
PBC36DAAN
RAPC722X
SJ-3523-SMT
HZ0805E601R-10
CBMF1608T470K
STD2805T4
RMCF0402FT562R
Rev. 0 | Page 43 of 45
UG-1135
Manufacturer
Murata
Murata
Panasonic
Murata
Panasonic
Murata
Murata
Panasonic
Murata
Murata
TDK Corp
Kemet
Murata
Murata
Murata
Murata
Murata
Murata
Lite-On
3M
3M
Switchcraft
CUI Inc.
Steward
Taiyo Yuden
STMicroelectronics
Stackpole
