Analog Devices EVAL-ADAU1466Z User Manual page 44

UG-1135
Qty. Designator
2 R1, R2
4 R13, R14, R19, R26
18 R16, R18, R22, R30, R33,
R37, R42, R49, R54, R57,
R60, R67, R77, R78, R82,
R88, R94, R98
6 R17, R45, R90, R92, R95,
R101
8 R20, R31, R39, R52, R58,
R75, R84, R96
8 R21, R32, R40, R53, R59,
R76, R85, R97
14 R23, R24, R27, R34, R36,
R41, R50, R55, R61, R71,
R72, R86, R89, R93
1 R25
16
R28, R29, R38, R44, R47,
R48, R56, R63, R65, R66,
R73, R81, R83, R87, R91,
R100
2 R3, R35
1 R4
5 R43, R51, R62, R80, R99
1 R5
4 R6, R9 to R11
6
R64, R68 to R70, R74,
R79
4 R7, R8, R15, R46
1 S1
1 S2
1 S3
68 TP1 to TP9, TP14 to
TP25, TP30 to TP76
1 U1
1 U10
1 U14
1 U2
1 U3
1 U4
1 U5
9 U6, U8, U9, U11 to U13,
U15 to U17
1 U7
1 Y1
Description
Potentiometer, 10 kΩ, linear taper, 9 mm, vertical
Chip resistor, 1 kΩ, 1%, 63 mW, thick film, 0402
Chip resistor, 49.9 Ω, 1%, 63 mW, thick film, 0402
Chip resistor, 10 kΩ, 1%, 100 mW, thick film, 0402
Chip resistor, 768 Ω, 1%, 63mW, thick film, 0402
Chip resistor, 13kΩ, 1%, 63 mW, thick film, 0402
Chip resistor, 100 kΩ, 1%, 100 mW, thick film, 0402
Jumper, 0 Ω, 125 mW, 0805
Chip resistor, 4.99 Ω, 1%, 63 mW, thick film, 0402
Chip resistor, 4.75 kΩ, 1%, 63 mW, thick film, 0402
Chip resistor, 4.32 kΩ, 1%, 100 mW, thick film, 0402
Chip resistor, 100 Ω, 1%, 100 mW, thick film, 0402
Resistor network, eight-resistor, isolated, 33 Ω, 5%,
63 mW, 1506
Resistor, 0 Ω, 125 mW, 0603
Chip resistor, 475 Ω, 1%, 63 mW, thick film, 0402
Chip resistor, 33.2 Ω, 1%, 63 mW, thick film, 0402
Switch, top actuated, tactile, SPST normally open,
6 mm gull wing
Switch, SPDT slide, SMD J HOOK
Switch, four-section, SPST, SMD
Test point, white, 0.1 inch OD
Optical transmitter, 16 Mbps
EEPROM, 128k × 8, 1.8 V to 5.5 V, SOIJ-8
Inverter, 6-channel, SOIC-14
Optical receiver, 16 Mbps
SigmaDSP processor, 300 MHz
Codec, four-ADC, eight-DAC, 192 kHz, 24-bit
Voltage regulator, high accuracy, low dropout,
3.3 V dc
Op amp, dual, low power, low noise, low distortion,
rail-to-rail, 8-lead SOIC
Supervisor reset generator, 3.08 V, logic low
output, 4-lead SOT-143
Crystal, 12.288 MHz, 18 pF, SMD-4
Rev. 0 | Page 44 of 45
EVAL-ADAU1466Z
Part Number
EVU-F2MFL3B14
RC0402FR-071KL
RC0402FR-0749R9L
ERJ-2RKF1002X
RC0402FR-07768RL
RC0402FR-0713KL
ERJ-2RKF1003X
ERJ-6GEY0R00V
RMCF0402FT4K99
RC0402FR-074K75L
ERJ-2RKF4321X
ERJ-2RKF1000X
741X163330JP
ERJ-3GEY0R00V
RMCF0402FT475R
RMCF0402FT33R2
FSM6JSMA
CAS-120TA
219-4LPST
5002
PLT133/T10W
25AA1024-I/SM
74ACT04SC
PLR135/T10
ADAU1466WBCPZ
AD1938YSTZ
ADP3338AKCZ-3.3-R7
ADA4841-2YRZ
ADM811TARTZ-REEL7
ABM3B-12.288MHZ-10-1-U-T
User Guide
Manufacturer
Panasonic
Yageo
Yageo
Panasonic
Yageo
Yageo
Panasonic
Panasonic
Stackpole
Yageo
Panasonic
Panasonic
CTS
Panasonic
Stackpole
Stackpole
Tyco/Alcoswitch
Copal Electronics
CTS Corp
Keystone
Electronics
Everlight
Microchip
Fairchild Semi
Everlight
Analog Devices
Analog Devices
Analog Devices
Analog Devices
Analog Devices
Abracon Corp
