EVAL-ADAU1466Z
Table 4. Multipurpose Pins and Hardware Access Points
MP Pin Connection
LRCLK_OUT1/MP5 Input to inverter (LED D4)
LRCLK_OUT3/MP9 Input to inverter (LED D3)
LRCLK_IN1/MP11 Input to inverter (LED D5)
LRCLK_IN2/MP12 Pin multiplexed with LRCLK_IN2
LRCLK_IN3/MP13 Pin multiplexed with LRCLK_IN3
To configure the operation of the multipurpose pins, navigate to
the MULTIPURPOSE tab in the Hardware Configuration tab
in SigmaStudio (see Figure 65).
Figure 65. Multipurpose Pin Configuration in

AUXILIARY ADC PINS

The ADAU1466 has a 10 bit, successive approximation
register (SAR) ADC multiplexed across six input channels.
Channel AUXADC0 and Channel AUXADC1 are connected
to linear Potentiometer R1 and Potentiometer R2.
Channel AUXADC2 to Channel AUXADC5 are accessible
on test points next to the ADAU1466. Inputs to the ADCs
between 0 V and 3.3 V can be connected to these pads and then
used in the SigmaStudio signal flow (see Figure 66).
User Guide
SigmaStudio
Figure 66. Potentiometers and Copper Pads for Inputting Signals to the
COMMUNICATIONS HEADER
The communications header is a 10-pin header designed to work
with the EVAL-ADUSB2EBZ
from the communications header to the corresponding SPI slave
port pins on the ADAU1466. The I
design. A reset line is also included, which allows the user to
reset the devices on the board via a command in SigmaStudio.
When the USBi
recognizes the
(see Figure 10).
Rev. 0 | Page 21 of 45
Access Point
TP56
TP48
TP29
Header J3, Pin 4
Header J2, Pin 4
Auxiliary ADC
or USBi. The SPI signals are wired
2
C pins are not used in this
is connected and powered and the computer
USBi on its USB 2.0 port, LED D1 illuminates
UG-1135
