MAX98360 Evaluation Systems
Audio Interface Board III
Maxim's Audio Interface board III (AUDINT3 board) facilitates
the evaluation of the DEV board by providing a set of
features that can be used to exercise the capabilities of
the DEV board without the need for additional audio
equipment. The main components of the AUDINT3
board are the LDO supply voltages and the USB-to-PCM
interfaces. The supply voltages allow the DEV board to be
evaluated with minimal amount of external supplies. The
USB-to-PCM converter allows any computer to be used
as an audio source for the DEV board's digital audio PCM
interface.

Ordering Information

PART
MAX98360AEVSYS#FCQFN
MAX98360BEVSYS#FCQFN
MAX98360CEVSYS#FCQFN
MAX98360DEVSYS#FCQFN
#Denotes RoHS compliant.
www.analog.com
TYPE
Complete Evaluation System
Complete Evaluation System
Complete Evaluation System
Complete Evaluation System
Evaluates: MAX98360A/MAX98360B/
MAX98360C/MAX98360D (FCQFN)
The MAX98360 DEV board connects to the AUDINT3
board through connector J1. The physical connections
made between the DEV board and AUDINT3 board are
listed in Table 8.
USB Audio Input
To utilize the USB streaming feature of the AUDINT3
board, connect the USB cables from your computer to
the USB connector J2 on the AUDINT3 board and ensure
that the AUDINT3 board is connected to the DEV board.
