Ordering Information; Bill Of Materials - Analog Devices ADP5055-EVALZ User Manual

ADP5055-EVALZ

ORDERING INFORMATION

BILL OF MATERIALS

Table 4.
Qty. Reference Designator
1 C1
1 C2
3 C4, C5, C8
16 C6, C7, C10 to C13, C23 to C28, C39 to C42
3 C14, C22, C35
2 C18, C34
5 C36, C57, C61 to C63
3 C17, C19, C20
4 C3, C9, C15, C16
1 C48
1 C49
1 D1
4 J-EN1, J-EN2, J-EN3, J_SYNC
2 S1, S2
8 J11 to J18
2 L1, L2
1 L3
1 R1
3 R2, R13, R23
2 R5, R14
2 R6, R16
1 R7
1 R17
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
User Guide
Description
Ceramic capacitor, 4.7 μF, X6S, 25 V,
10%, 0603
Ceramic capacitor, 4.7 μF, X6S, 6.3 V,
20%, 0402
Ceramic capacitors, 180 pF, C0G,
50 V, 1%, 0402
Ceramic capacitors, 47 μF, 6.3 V,
20%, 0805
Ceramic capacitors, 0.1 μF, X7R, 16 V,
10%, 0402
Ceramic capacitors, 1 nF, 50 V, 5%,
0402
Ceramic capacitors, 10 μF, X7S, 25 V,
10%, 0805
Ceramic capacitors, 10 μF, X5R, 10 V,
10%, 0603
Capacitors, do not install (DNI)
Ceramic capacitor, 470 pF, C0G, 50 V,
5%, 0402
Resistor, SMD 0 Ω jumper, 1/10 W,
0603
Clear green LED, 0603, surface-
mount device (SMD)
2.54 mm, 3-pin headers
2.54 mm, 2-pin headers
Noninsulated jacks, .218 inches
Inductors, 0.8 μH
Inductor, 2.2 μH
Resistor, SMD, 280 kΩ, 1%, 1/16 W,
0402
Resistors, SMD, 20 kΩ, 1%, 1/16 W,
0402
Resistors, SMD, 402 kΩ, 1%, 1/16 W,
0402
Resistors, SMD, 22.1 kΩ, 1%, 1/16 W,
0402
Resistor, SMD, 30.1 kΩ, 1%, 1/16 W,
0402
Resistor, SMD, 16.9 kΩ, 1%, 1/16 W,
0402
Manufacturer
Murata
Murata
Murata
Murata/Taiyo Yuden
KEMET
Murata
Murata
Murata
Not applicable
Murata
Vishay Dale
LITE-ON
Wurth
Wurth
Keystone Electronics
Coilcraft
Coilcraft
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Rev. 0 | Page 15 of 16
UG-1930
Part Number
GRM188C81E475KE11
GRM155C80J475MEAA
GCM1555C1H181FA16D
GRM21BR60J476ME11,
MK212BJ476MG-T
C0402C104K4RACTU
GRM1555C1H102JA01
GRM21BC71E106KE11
GRM188R61A106KAAL
Not applicable
GRT1555C1H471JA02
CRCW06030000Z0EA
LTST-C191KGKT
61300311121
61300311121
575-4
XAL5030-801ME
XEL4030-222ME
CRCW0402280KFKED
CRCW040220K0FKED
CRCW0402402KFKED
CRCW040222K1FKED
CRCW040230K1FKED
CRCW040216K9FKED
