UG-139

ORDERING INFORMATION

BILL OF MATERIALS

Table 1. Demo Daughterboard Bill of Materials
Qty Reference Designator
2 C1, C2
1 R1
1 R2
1 R3
1 D1
1 D3
6 J1 to J5, J7
1 J6
1 J11
1 JP1
1 L1
15
TP1, TP10 to TP14, TP21, TP23 to
TP28, TP30, TP31
1 U1
1 U2
Table 2. LED Subboard Bill of Materials
Qty Reference Designator
1 D1
1 R1
1 R2
6 J1, J2, J3, J4
Table 3. Motherboard Bill of Materials
Qty Reference Designator
1 C7
9 C5, C13, C15 to C18, C22, C23,
C30
2 C11, C25
1 C31
2 C8, C9
1 C19
2 C128, C132
1 C12
2 C10, C24
2 C129, C130
1 C14
2 C127, C131
2 R19, R31
2 R21, R36
2 R33, R34
N/A R37, R38
1 R22
4 R24, R25, R30, R32
4 R28, R29, R35, R39
6 R62 to R66, R68
Description
Capacitor, MLCC, 10 μF, 6.3 V/4.0 V, 0603,
X5R
Resistor, open, 1%, 0805, 270 kΩ, SMD
Resistor, open, 1%, 0603, 0 Ω, SMD
Resistor, 0 Ω, 1%, 0402, 0.125 W, SMD
White LED, open when you plug LED
subboard
Indicator LED, red, 0402
Connector header, two pins × 1
Terminal block, two pins × 1
Connector header, 10 pins × 1
Connector header, 10 pins × 2
Inductor, 1.0 μH, 3 mm × 3 mm
Connector header, 1 pin × 1
ADP1650, 12-ball WLCSP
ADP1650 plug-in LED boards, six pcs gold
sockets
Description
White LED
Resistor, 267 kΩ, 1%, 0805, SMD
Thermistor, PTC, 470 Ω, 0603, SMD
Gold pin (plug into demo/evaluation board)
Description
Capacitor, MLCC, 10 μF, 10 V, 0805, X5R
Capacitor, MLCC,100 nF,16 V, 0402, X5R
Capacitor, MLCC, 2.2 μF,10 V, 0603, X5R
Capacitor, MLCC, 47 μF, 10 V, 1210, X5R
Capacitor, MLCC, 6.2 pF, 50 V, 0402, COG
Capacitor, MLCC, 1 μF, 10 V, 0402, X5R
Capacitor, MLCC, 1 μF, 10 V, 0603, X5R
Capacitor, MLCC, 1 μF, 25 V, 0805, X7R
Capacitor, MLCC, 10 nF, 50 V, 0402, X7R
Capacitor, MLCC, 10 nF, 50 V, 0603, X7R
Capacitor, MLCC, 1 nF, 50 V, 0402, X7R
Capacitor, MLCC, 4.7 μF, 6.3 V, 0603, X5R
Resistor, 1 kΩ, 1%, 0402, SMD
Resistor, 100 kΩ, 1%, 0402, SMD
Resistor, 330 Ω, 1%, 0402, SMD
Open
Resistor, 10 kΩ, 1%, 0402, SMD
Resistor, 1.5 kΩ, 1%, 0402, SMD
Resistor, 4.7 kΩ, 1%, 0402, SMD
Resistor, 0 Ω, 1%, 0402, SMD
Rev. A | Page 14 of 16
Evaluation Board User Guide
Manufacturer/Vendor Part Number
Murata, TDK GRM188R60J106ME,
C1608X5R0G106MT
Vishay or equivalent CRCW0805270KFKEA
Vishay or equivalent CRCW06030000Z0TA
Vishay or equivalent CRCW04020000Z0EDHP
OSRAM/LumiLEDs LUWC9SP or PWF4
Lumex SML-LX0402SIC-TR
Samtec TSW-150-07-T-S
Sullins PEC36SAAN
Samtec SSQ-110-01-G-S
Samtec SSW-110-03-G-D
TOKO FDSD0312-1R0M,
FDSE0312-1R0M
Samtec TSW-150-07-T-S
Analog Devices ADP1650
Kensington YSK0076-011AH
Manufacturer/Vendor Part Number
OSRAM/LumiLEDs LUWC9SP or PWF4
Vishay or Equivalent CRCW0805267KFKEA
Murata PRF18BE471QB1RB
Kensington HSP030M2H
Manufacturer/Vendor Part Number
Murata GRM219R61A106K
Murata GRM155R71C104K
Murata GRM188R61A225K
Murata GRM32ER61A476K
Murata GRM1555C1H6R2B
Murata GRM155R61A105K
Murata GRM188R61A105K
Murata GRM21BR71E105K
Murata GRM155R71H103K
Murata GRM188R71H103K
Murata GRM155R71H102K
Murata GRM188R60J475K
Vishay or equivalent CRCW04021K00FKED
Vishay or equivalent CRCW0402100KFKED
Vishay or equivalent CRCW0402330RFKED
No assembly No assembly
Vishay or equivalent CRCW040210K0FKED
Vishay or equivalent CRCW04021K50FKED
Vishay or equivalent CRCW04024K70FKED
Vishay or equivalent CRCW04020000Z0EDHP
