Evaluation Board User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 4.
Qty Reference Designator
Integrated Circuits
3 U1, U5, U6
1 U2
1 U3
1 U4
1 Y1
2 D1, D2
1 L1
1 D3
Capacitors
4 C1 to C4
2 C5, C6
15 C8, C9, C11, C15, C16, C18, C22, C23, C25
to C31
3 C7, C10, C14, C21, C24
2 C12, C13
1 C17
2 C19, C20
Resistors
7 R1 to R4, R9, R18
2 R5, R6
4 R10 to R15
2 R16, R17
4 R19
1 R7, R20
2 R21, R22
Links
13 LK1 to LK4, LK6 to LK14, (2 × 1 way)
2 LK15, LK16 (3 × 1 way)
1 LK5 (3 × 2 way)
16 At LK1 to LK16
Connectors
4 AIN+, AIN−, REFIN+, REFIN−
1 J1
2 J3, J4
1 J2
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
Description
24-bit Σ-Δ ADC
USB controller
EEPROM
3.3 V Regulator
24 MHz crystal
Green LED
Ferrite bead
Diode
Capacitors
100 pF ceramic
0.1 μF ± 10% ceramic
10 μF tantalum
1 μF ceramic
2.2 μF tantalum
12 pF ceramic
0 Ω resistor
5 kΩ resistor
1 MΩ resistor
100 kΩ resistor
10 kΩ resistor
1 kΩ resistor
2.2 kΩ resistor
Pin headers
Pin headers
Pin headers
Shorting plugs
SMB connector
USB Mini-B connector
3-way terminal block
2-way terminal block
Rev. 0 | Page 13 of 16
Manufacturer, Part No.
Analog Devices, AD7780BRZ
Cypress Semiconductor Corporation, CY7C68013A-
56LFXC
Microchip Technology, Inc., 24LC64-I/SN
Analog Devices, ADP3303ARZ-3.3
AEL Crystals, X24M000000S244
Kingbright, Elec. Co., Ltd, KP-2012SGC
Meggitt Sigma, BMB2A0300AN1
Micro Commercial Components Corp., DL4001-TP
Not inserted
AVX Corporation, 06035A101JAT2A
AVX Corporation, CM105X7R104K16AT
AVX Corporation, TAJA106M016R
Yageo Corporation, 2238 246 19863
EPCOS AG, B45196E2225K109
Phycomp, 2238 867 15129
Phycomp, 232270296001
Tyco Electronics, RN73C2A4K99BTG
Multicomp, MC 0.063W 0603 1% 1M
Multicomp, MC 0.063W 0603 1% 100K
Multicomp, MC 0.063W 0603 1% 10K
Multicomp, MC 0.063W 0603 1% 1K
Multicomp, MC 0.063W 0603 1% 2K2
Harwin Plc, M20-9990246
Harwin Plc, M20-9990246
Harwin Plc, M20-9980346
Harwin Plc, M7566-05
Not inserted
Molex, 565790576
Phoenix, 1725672
Camden Electronics Ltd., CTB5000/2
