Ordering Information; Bill Of Materials - Analog Devices LTC3303A User Manual

User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 2. DC3252A Bill of Materials
Item
Required Circuit Components
1
2
3
4
5
6
7
8
9
10
Additional Demo Board Circuit Components
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
analog.com
Arrow.com.
Downloaded from
Quantity Reference Designator
1 C1
1 C2
1 C3
1 C4
2 C5, C6
1 L1
1 R1
1 R2
1 R10
1 U1
0 C7, C8
1 C9
0 C10
2 C11, C12
1 C13
2 C14, C15
1 L2
1 Q1
1 R3
1 R4
1 R5
1 R6
1 R7
1 R8
1 R9
0 R11
0 R12 to R15
Part Description
Capacitor, 10 µF, X7T, 10 V, 20%, 0603,
AEC-Q200
Capacitor, 1 µF, X7S, 10 V, 10%, 0402,
AEC-Q200, no substitutes allowed
Capacitor, 1 µF, X7T, 6.3 V, 20%, 0201,
AEC-Q200
Capacitor, 33 pF, C0G, 50 V, 5%, 0402
Capacitors, 22 µF, X7T, 6.3 V, 20%, 0805,
AEC-Q200
Inductor, 330 nH, fixed, ±20%, 4.3 A, 31
mΩ, 0806, AEC-Q200
Resistor, 14.3 kΩ, 1%, 1/16 W, 0402
Resistor, 20 kΩ, 1%, 1/16 W, 0402, AEC-
Q200
Resistor, 10 Ω, 5%, 1/20 W, 0201
IC, 5 V, 4 A, 2 MHz, synchronous step-
down regulator
Capacitors, option, 0805
Capacitor, 1000 pF, X7R, 50 V, 20%,
0402, 3-Term, X2Y EMI filter
Capacitor, 0.1 µF, X7R, 10 V, 10%, 0402,
AEC-Q200
Capacitors, 330 µF, Tantalum, POSCAP
TPE, 6.3 V, 20%, 7343, 25 mΩ
Capacitor, 0.1 µF, X7R, 10 V, 10%, 0402,
AEC-Q200
Capacitors, 10 µF, X7T, 10 V, 20%, 0603,
AEC-Q200
Inductor, ferrite bead, 100 Ω at 100 MHz,
25%, 8 A, 6 mΩ, 1812, AEC-Q200
Transistor, N-MOSFET, 40 V, 15.9 A,
PPAK SO-8
Resistor, 20 Ω, 1%, 1/16 W, 0402, AEC-
Q200
Resistor, 100 kΩ, 5%, 1/16 W, 0402
Resistor, 1 mΩ, 1%, 1/16 W, 0402, AEC-
Q200
Resistor, 249 kΩ, 1%, 1/16 W, 0402, AEC-
Q200
Resistor, 10 kΩ, 5%, 1/10 W, 0402, AEC-
Q200
Resistor, 0.1 Ω, 1%, 2 W, 2512, sense,
AEC-Q200
Resistor, 10 kΩ, 5%, 1/16 W, 0402, AEC-
Q200
Resistor, 49.9 kΩ, 1%, 1/16 W, 0402,
AEC-Q200
Resistors, option, 0402
DC3252A
Manufacturer, Part Number
Murata, GRT188D71A106ME13D
Murata, GCM155C71A105KE38D
Murata, GRT033D70J105ME13D
AVX, 04025A330JAT2A
TDK, CGA4J1X7T0J226M125AC
TDK, TFM201610ALMAR33MTAA
Vishay, CRCW040214K3FKED
Vishay, CRCW040220K0FKED
Vishay, CRCW020110R0JNED
Analog Devices Inc.,
LTC3303ARUCM#TRPBF
Not applicable
Johanson Dielectrics, 500X07W102MV4T
Murata, GCM155R71A104KA55D
Panasonic, 6TPE330ML
Murata, GCM155R71A104KA55D
Murata, GRT188D71A106ME13D
Wurth Elektronik, 78279226101
Vishay, SIR426DP-T1-GE3
Vishay, CRCW040220R0FKED
Yageo, RC0402JR-07100KL
Vishay, CRCW04021M00FKED
Vishay, CRCW0402249KFKED
Panasonic, ERJ2GEJ103X
TT Electronics, LRC-LR2512LF-01-R100-F
Vishay, CRCW040210K0JNED
Vishay, CRCW040249K9FKED
Not applicable
Rev. 0 | 12 of 13
