ORDERING INFORMATION

BILL OF MATERIALS

Table 2. ADMV8502-EVALZ
Quantity Reference Designator
3 2P5V, 3P3V, TP_VPO
2 GND1, GND2
2 N2P5V, TP_VNE
5 CSB_EX, RF1, RF2, VNEG, VPOS
3 C1 to C3
7 C11 to C17
6 C21, C22, C25 to C28
6 C31 to C33, C37 to C39
1 C4
1 D1
3 DS1 to DS3
1 L1
1 P1
1 P2
11 R1 to R11
6 R12 to R17
11 R21 to R24, R28 to R34
2 R53, R54
1 R61
1 R71
1 R81
1 R91
1 S1
1 U1
1 U2
1 U4
1 U5
1 U6
1 U7
2 C18, C19
2 C23, C24
3 C34 to C36
6 C81 to C86
12 R25 to R27, R40 to R48
4 R49 to R52
2 THRU1, THRU2
1 U3
analog.com
Description
Test points, red
Test points, black
Test points, blue
Connectors, edge launch, SMA
Capacitors, 100 pF, 50 V, 5%, 0402
Capacitors, 0.1 µF, 16 V, 5%, 0402
Capacitors, 10 µF, 16 V, 10%, 0805
Capacitors, 1 µF, 6.3 V, 10%, 0402
Capacitor, 47 µF, 10 V, 10%, 1210
Diode, BAT54H, 30 V, SOD123F
LED, LTST-C190GKT, green, 0603
Coupled Inductor, 22 μH, 20%
Connector, vertical, surface-mount technology
(SMT), 120-pin
Connector, vertical, header, 10-pin
Resistors, 330 Ω, 1/10 W, 5%, 0402
Resistors, 33 Ω, 1/10 W, 1%, 0402
Resistors, 0 Ω, 1/16 W, 0402
Resistors, 100 kΩ, 1/16 W, 5%, 0402
Resistor, 29.4 kΩ, 1/10 W, 1%, 0402
Resistor, 24.9 kΩ, 1/10 W, 1%, 0402
Resistor, 49.9 Ω, 1/10 W, 1%, 0402
Resistor, 750 Ω, 1/16 W, 5%, 0402
Switch, mechanical, slide, DPDT, 0.2 A
IC, 90 MHz to 225 MHz, digitally tunable
band-pass filter
IC, LDO regulator, 3.3 V
IC, inverting DC-to-DC converter
IC, LDO regulator, –2.5 V
2
IC, 24LC32A, EEPROM, I C
IC, CMOS SPDT switch
Capacitors, 0.1 µF, 16 V, 5%, 0402, do not
install (DNI)
Capacitors, 10 µF, 16 V, 10%, 0805, DNI
Capacitors, 1 µF, 6.3 V, 10%, 0402, DNI
Capacitor, 10 pF, 50 V, 5%, 0402, DNI
Resistors, 0 Ω, 1/16 W, 0402, DNI
Resistors, 100 kΩ, 1/16 W, 5%, 0402, DNI
Connectors, edge launch, SMA, DNI
IC, LDO regulator, 2.5 V, DNI
EVAL-ADMV8502
Manufacturer Part Number
Components Corporation TP-104-01-02
Components Corporation TP-104-01-00
Components Corporation TP-104-01-06
Cinch Connectivity 142-0701-851
Johanson Dielectrics 500R07N101JV4T
Kemet C0402C104J4RACTU
Samsung CL21B106KOQNNNE
Murata GRM155R70J105KA12D
Murata GRM32ER71A476KE15L
NXP Semiconductor BAT54H,115
Lite-On Technology LTST-C190GKT
Coilcraft LPD5030-223MRC
Hirose Electric Co. FX8-120S-SV(21)
Harwin Inc. M20-9980546
Panasonic ERJ-2GEJ331X
Panasonic ERJ-2RKF33R0X
Stackpole RMCF0402ZT0R00
Yageo RC0402JR-07100KL
Panasonic ERJ-2RKF2942X
Panasonic ERJ-2RKF2492X
Panasonic ERJ-2RKF49R9X
Panasonic ERJ-2GEJ751X
Nidec Copal Electronics CL-SB-22A-11T
Analog Devices ADMV8502ACCZ
Analog Devices ADP7156ACPZ-3.3-R7
Analog Devices LT1617ES5-1#PBF
Analog Devices ADP7183ACPZN2.5-R7
Microchip Technology 24LC32A-I/MS
Analog Devices ADG749BKSZ
Kemet C0402C104J4RACTU
Samsung CL21B106KOQNNNE
Murata GRM155R70J105KA12D
Yageo CC0402JRNPO9BN100
Stackpole RMCF0402ZT0R00
Yageo RC0402JR-07100KL
Cinch Connectivity 142-0701-851
Analog Devices ADP7156ACPZ-2.5-R7
