Evaluation Board User Guide

Ordering Information

Bill of Materials
Item Qty. Reference Designator
1 1 U1
2 8 C1, C2, C3, C4, C30, C31,
C32, C33
3 9 C10, C11, C20, C21, C26,
C27, C28, C29, C38
4 21 C12, C13, C15, C16, C17,
C22, C23, C24, C25, C34,
C37, C39, C40, C41, C42,
C43, C44, C45, C46, C47,
C49
5 6 5V_VIN, INN, INP, OUT_1,
SDN_IO, SYNC_01
6 1 AVDD
7 2 C35, C36
8 3 C5, C6, C7
9 2 D1, D2
10 2 D3, D4
11 2 DVDD, SDNRST
12 10 FAN_GND, GND_1, GND_2,
GND_3, GND_4, GND_5,
GND_8, GND_9, GND_10,
REFIC_IN
13 2 FAN_PWM, VEE_HV
14 2 FAN_VCC, VCC_HV
15 1 OUT
16 4 OUT_RES, P2, P8, VMID
analog.com
Part Description
IC, high-voltage, high-
current amplifier
Capacitor, ceramic, 1.2
μF, 250 V, 10%, X7R,
2225
Capacitor, ceramic, 0.1
μF, 250 V, 10%, X7R,
1206
Capacitor, ceramic, 0.1
μF, 16 V, 10%, X7R,
0603
Connector-PCB, SMT
test point
Connector-PCB, test
point orange
Capacitor, ceramic, 1.2
μF,10 V,10%,X5R,
0805
Capacitor, tantalum, 10
μF,16 V,10%, 3216 to
3218
Diode, Schottky
rectifier, 20 A, 150 V
Diode, Schottky
rectifier, 3 A, 60V
Connector-PCB, test
point yellow
Connector-PCB, test
point black
Connector-PCB, test
point blue
Connector-PCB, test
point red
Connector-PCB,
surface mount
assembly (SMA) end
launch
Connector-PCB, 2
position header
Manufacturer, Part No.
Analog Devices, AD8460BSVZ
Kemet, C2225C125KARACTU
Kemet, C1206X104KARACTU
Yageo, CC0603KRX7R7BB104
Keystone Electronics, 5015
Components Corporation, TP104-01-03
Kemet, C0805C125K8PACTU
Kemet, T491A106K016AT
On Semiconductor/MBR20H150CTG
Vishay/SS36-E3/57T
Components Corporation, TP-104-01-04
Components Corporation, TP-104-01-00
Components Corporation, TP104-01-06
Components Corporation, TP-104-01-02
Cinch Connectivity Solutions, 142-0701-
801
Samtec, TSW-102-09-G-S
AD8460
Rev.0 20 of 31
