Extended Error Information Field; Section 9.7 Error Codes - Spectrum Controls 1769sc-IF4IH User Manual

9-4
Compact IO™ Isolated HART Analog Input Module
Section 9.7
Error Codes
User' s Manual 0300215-03 Rev. A
Table 9-3 (Module Error Types)
Error Type Module Error Field
Value Bits 11
through 9 (binary)
No errors 000
Hardware 001
Errors
Configuration 010
Errors

9.6.2 Extended Error Information Field

Check the extended error information field when a non-zero value is present in the
module error field. Depending upon the value in the module error field, the extended
error information field can contain error codes that are module-specific or common to all
1769 analog modules.
Note: If no errors are present in the module error field, the extended error
information field is set to zero.
Hardware Errors
General or module-specific hardware errors are indicated by module error code 001. See
Table 9-4 (Extended Fault Codes).
Configuration Errors
If you set the fields in the configuration file to invalid or unsupported values, the module
generates a critical error.
Table 9-4 (Extended Fault Codes) lists the possible module-specific configuration error
codes defined for the module.
The table below explains the extended error code.
Description
No error is present. The extended error field holds no
additional informat ion.
General and specific hardware error codes are s pec ified in
the extended error information field.
Module-specific error codes are indicated in the extended
error field. These error codes correspond to options that
you can change directly. For example, the input range or
input filter selection.
