Chapter 2: Quick Start For Experienced Users
User' s Manual 0300215-03 Rev. A
Step 7: Monitor the module status to
check if the module is operating
correctly
Module and channel configuration errors are reported to the controller. These errors are
typically reported in the controller's I/O status file. Channel status data is also reported in
the module's input data table, so these bits can be used in your control program to flag a
channel error.
Reference
Chapter 9 (Diagnostics and
Troubleshooting)
2-5
