Spectrum Controls 1769sc-IF4IH User Manual page 74

7-6
Compact IO™ Isolated HART Analog Input Module
Table 7-2 (HART Packet 1)
Tag Name
1
If4ih0Packet1
If4ih0Packet1[X,0]
If4ih0Packet1[X,0].HartChannelID
If4ih0Packet1[X,0].HartCommStatus
If4ih0Packet1[X,0].HartDevStatus
If4ih0Packet1[X,0].HartPV
If4ih0Packet1[X,0].HartSV
If4ih0Packet1[X,0].HartTV
If4ih0Packet1[X,0].HartFV
If4ih0Packet1[X,0].HartPVUnits
If4ih0Packet1[X,0].HartSVUnits
If4ih0Packet1[X,0].HartTVUnits
If4ih0Packet1[X,0].HartFVUnits
If4ih0Packet1[X,0].PV_Assignment
If4ih0Packet1[X,0].SV_Assignment
If4ih0Packet1[X,0].TV_Assignment
If4ih0Packet1[X,0].FV_Assignment
If4ih0Packet1[X,0].RangeLow
If4ih0Packet1[X,0].RangeHi
If4ih0Packet1[X,0].Pad
1
X represent s the module channel number (0 t o 3)
User' s Manual 0300215-03 Rev. A
1
Data Type Style Description
Packet1[4,1] NA Two dimensional array containing packet
1 data for all 4 channels.
Packet1 NA Packet 1 data for channel X
INT BIN Bits 0 to 3: Channel number (0 – 3).
Bit 4: Searching/Initializing HART device
Bit 5: HART communication failure or
device not found
Bit 6: Pass-through message pending (ready)
Bit 7: Unused (0)
Bits 8 to 10: Packet ID
Bit 11 through 15: Unused
SINT BIN HART commun icati on status byte. Refer to appendi x D
for more details.
SINT BIN HART device st at us byte. Refer to appendix D for more
detail s.
HART Pri mary Variable
REAL FLOAT
REAL FLOAT HART Secondary Variable
HART Tertiary Variable
REAL FLOAT
REAL FLOAT HART Fourth Variable
SINT DEC HART Pri mary Variable units code
SINT DEC HART Secondary Variable units code
SINT DEC HART Tertiary Variable units code
SINT DEC HART Fourth Variable un its code
SINT DEC HART Pri mary Variable code
SINT DEC HART Secondary Variable code
HART Tertiary Variable code
SINT DEC
SINT DEC HART Fourth Variable code
REAL FLOAT Low transmitter range for analog signal in
engineering units
REAL FLOAT High transmitter range for analog signal in
engineering units
SINT[4] DEC Packet pad (32 bit alignment )
