A-2
Compact IO™ Isolated HART Analog Input Module
Section A.2
Environmental
Specifications
User' s Manual 0300215-03 Rev. A
Specification
Minimum Update Time
Maximum Update Time
Isolation
Channel to Rack
Channel to Channel
PCB spacing
Isolation spacing requirements
PCB spacing
Non-PCB spacing
Through Air
Over Surface
Input Protection
Power Requirements
Internal rack +5V
Internal rack +24V
Fusing
Test Description
Vibration/Shock
Unpack
Shock & Vibration (op)
Free Fall Unpackaged
(non-op)
Shock Unpackaged (op)
Packaging Tests
Temperature
Temp Cycle (op)
Thermal mapping of hot
comp
Storage Temperature
High temp (non-op)
Low temp (non-op)
Description
10 ms with 360 Hz filter
108 ms with 28.5 Hz filter
710 VDC or 500 VAC for one minute. Optical &
magnetic
710 VDC or 500 VAC for one minute. Optical &
magnetic
0.033in. (0.85mm)
0.033in. (0.85mm)
0.063in (1.59mm)
0.063in (1.7mm)
Voltage Terminal: +/- 24VDC continuous
Current Terminal: +/-28mA continuous, +/- 7 VDC
175 mA
60 mA
None
Standard
IEC 600 68-2-6 FC
ICCG-ES #001 A.
IEC 600 68-2-32#1
IEC 600 68-2-
27Ea
ICCG-ES #002 A.
NSTA
IEC 600 68-2-
14Nb
ICCG-ES #006 C.
IEC 600 68-2-2Bb
ICCG-ES #006 C.
IEC 600 68-2-2Ab
ICCG-ES #006 C.
Class/Limit
Class III
Class III, Cat. I
Will test new packaging
0 to 60 Degree C
0 to +60 2 cycles .5hr/cycle
done at 60 deg C, full load
-40 to 85 Degree C
+85 for 16hrs
-40 for 16hrs
