Section A.1
Electrical
Specifications
User' s Manual 0300215-03 Rev. A
Appendix A
Module Specifications
Specification
Configuration
Input Types
Normal Range:
Full Range:
Fault detection
CMRR
NMRR
Input Impedance
Voltage Terminal:
Currentl Terminal:
Overall Accuracy
Voltage Inputs:
Current Inputs:
Accuracy Drift
Voltage Inputs
Current Inputs
Data formats
Input Filter
Channel Update Time
Description
4 isolated channels of current/voltage inputs with an
ADC per channel w/ HART
+/-10V, 0–10V, 0–5V, 1-5V, 0–20mA, 4–20mA
+/-10.5V, -0.5–10.5V, -0.5–5.25V, 0.5-5.25V, 0–
21mA, 3.2–21mA
Over-range and Under-range error bits. Open circuit
detect for 4-20mA and all voltage ranges.
> -100 dB at 50 Hz (10 Hz filter)
> -100 dB at 50 Hz (50 Hz filter)
> -100 dB at 50 Hz (60 Hz filter)
> -75 dB at 50 Hz (250 Hz filter)
> -60 dB at 50 Hz (500 Hz filter)
> -100 dB at 60 Hz (10 Hz filter)
> -100 dB at 60 Hz (50 Hz filter)
> -100 dB at 60 Hz (60 Hz filter)
> -75 dB at 60 Hz (250 Hz filter)
> -60 dB at 60 Hz (500 Hz filter)
> -50 dB at 50 Hz (10 Hz filter)
> -50 dB at 50 Hz (50 Hz filter)
> -50 dB at 50 Hz (60 Hz filter)
> -50 dB at 60 Hz (10 Hz filter)
> -50 dB at 60 Hz (60 Hz filter)
> -50 dB at 60 Hz (60 Hz filter)
>1M ohms (nominal)
249 ohms (nominal)
Includes offset, gain, non-linearity and repeatability
errors
+/- 0.2% of full scale @ 25°C
+/- 0.3% of full scale @ 0-60°C
+/- 0.35% of full scale @ 25°C
+/- 0.5% of full scale @ 0-60°C
+/-0.003%/°C
+/-0.0045%/°C
Engineering units, Scaled for PID, Percent of Full
Scale, RAW/Proportional counts
28.5 Hz, 50 Hz, 60.0 Hz, 300 Hz, 360 Hz
See 6.7.1
