Table 7-1 (HART Packet 0)
Tag Name
If4ih0Packet0
If4ih0Packet0[X,0]
If4ih0Packet0[X,0].HartChannelID
If4ih0Packet0[X,0].ManufacturerID
If4ih0Packet0[X,0].DeviceType
If4ih0Packet0[X,0].NumPreambles
If4ih0Packet0[X,0].UniversalCmdCode
If4ih0Packet0[X,0].XmitterRev
If4ih0Packet0[X,0].SwRev
If4ih0Packet0[X,0].HwRev
If4ih0Packet0[X,0].HartFlags
If4ih0Packet0[X,0].RangeUnits
If4ih0Packet0[X,0].DeviceSerialNumber
If4ih0Packet0[X,0].DeviceTag
If4ih0Packet0[X,0].DeviceDescriptor
1
X represents the module channel number (0 to 3)
User' s Manual 0300215-03 Rev. A
Chapter 7: Enabling and Using HART on the 1769sc-IF4IH0
1
Data Type
Style Description
Packet0[4,1] NA
Two dimmensional array containing
packet 0 data for all 4 channels.
Packet0
NA
Packet 0 data for channel X
INT
BIN
Bits 0 to 3: Channel number (0 – 3).
Bit 4: Searching/Initializing HART device
Bit 5: HART communication failure or
device not found
Bit 6: Pass-through message pending (ready)
Bit 7: Unused (0)
Bits 8 to 10: Packet ID
Bit 11 through 15: Unused
SINT
DEC
HART device Manufacturer ID
SINT
DEC
HART device type code
SINT
DEC
Minimum number of preambles the device
requires.
SINT
DEC
HART Universal command set 5.0
SINT
DEC
HART Transmitter specific revision
SINT
DEC
HART device software revision number
SINT
DEC
HART device hardware revision number
SINT
BIN
HART flags
SINT
DEC
Units code for range parameter
SINT[3]
HEX
HART device ID number
SINT[8]
ASCII 8 character device tag
SINT[16]
ASCII
7-5
