Chapter 8 - Address Book
General Settings
Figure 8-2
The table below explains the detailed meanings of these parameters.
Table 8-1
Parameter
Name
IP Address
Alias
Cascade
Dialing Direction
Extension
DTMF
Audio only
Example of cascading configuration
There are two set of cascaded RMX devices (RMX 1000_1 and RMX 1000_2).
8-2
New Participants – General
Configuration Description of New Participants – General
Description
Enter a name to identify the participant.
Enter the IP address of the participant's endpoint. This item is
optional if an alias is set in the Alias check box below.
Set the alias of the participant's endpoint: Select the alias type
H.323 or E.164 from the drop-down list, and then enter the
alias. This item is optional if the IP address of the endpoint is
set.
If the device is a standard endpoint, select No Cascade.
If the device will be a cascaded link to another MCU, set the
master/slave relationship of the RMX 1000 relative to the
participant: If the RMX 1000 is the master, select Master,
otherwise select Slave. In the cascading mode, you need to set
the following three items: Dialing Direction, Extension, and
DTMF.
Select the dialing direction:
Dial-in: The participant's device dials in the conference at the
local RMX 1000. It is unnecessary to set the items Extension
and DTMF if this option is selected.
Dial-out: The local RMX 1000 dials out to the participant's
device.
Use this field in case the user would like to send an extension
field to the remote end.
Enter a DTMF code that will be sent upon connection to the
remote end.
If this option is selected, the participant will be defined as an
audio participant, and the system does not support video input
and output capabilities.
