Chapter 1- Hardware Description
1-38

RTM ISDN

The following LEDs appear on the RTM ISDN:
Table 1-15 RMX 4000 RTM ISDN LEDs
LED
Function Name
Name
LAN LEDs (LAN LNK
1-6)
1 Gb
ShMC LED H/S
LED Color Description
Green ON with an active network
connection, flickers with Packet
activity.
Amber ON when 1Gb connection is
online, flickers with Packet
activity.
Blue OFF - Normal.
Flashes - This LED is activated
when the MPM+/MPMx card
Hot Swap functionality initiates
a power off routine on the
MPM+/MPMx cards.
ON - Power on the RTM ISDN
card has been switched OFF.
This LED is activated by the
card when the MPM+/MPMx's
card Hot Swap functionality
powers off the MPM+/MPMx
cards.
