Polycom RMX 4000 Hardware Guide
Table 1-12 RMX 4000 Front Panel LED's (Continued)
Component LED ID
CNTL 4000 Unit ERR
RDY
ACT
HD
HS
LED Color Description
Red ON - Major system error. In case of
an active alarm this light is ON, and
the RDY green is OFF.
OFF - Normal.
Flashes - During system startup.
Green ON - CPU card has successfully
completed startup. This light turns
green after completing the entire
system configuration.
OFF - Turns OFF when the ERR
red LED is activated.
Flashes - During system startup.
Amber ON - At least one endpoint is
connected to the system.
Flashes - During system startup.
Red OFF - Normal.
Flashes - Hard disk is active.
Blue Flashes - Indicates when the
power down process is initiated on
an MPM+/MPMx card. This LED
flashes in synchronization with the
MPM+/MPMx's cards HS LED.
OFF - Normal
ON - CPU may be removed.
1-35
