Chapter 1- Hardware Description
1-28
LAN 1- Modem
Connection & Management Net-
LEDs
work & LEDs
LAN 3 -
Signalling
network
Figure 1-11 RMX 4000 RTM-IP 4000 Rear Panel Layout
•
LAN 4, LAN 5 and the Serial ports are only for debugging and not for
customer use.
•
Do not remove the protective plastic caps from LAN 1, LAN 4 and LAN 5
ports.
The following items appear on the RMX 4000 rear panel:
Table 1-10 RMX 4000 Rear Panel - RTM-IP 4000 Component Description
Item
LAN 1
LAN 2 (CNTL
4000/CPU 1)
LAN 3 (CNTL
4000/CPU 1)
LAN 4-5 (CNTL
4000/CPU 2)
LAN 6
Serial
USB
LAN 6- 10/100Mb ShMG (Shelf
LAN 2-
Manager) & LEDs
LAN 4, 5 -
Empty
Description
Modem connection.
Note: LAN 1 is covered with a plastic cap that should not
be removed.
Management network/Web Client connection.
Signalling network, for Gatekeeper, Proxy or endpoint
connections.
Empty.
Shelf Manager connection.
A 10/100 ShMG Shelf Manager connection.
For debugging purposes only.
USB key connection - TBD.
Internal LAN Serial Port
connection
LEDs
USB Standby button
Port & LED
