Chapter 4 - Hardware Description
MGC+100 Components Location
ReadiConvene IAM
Shut Down
button
Compact Flash
slot
Universal
Serial Bus port
4-2
Figure 4-1 shows the front panel of the MGC+100. The front panel provides
access to the Main Control Module, the Functional Modules, and the Power
Supply Modules. Status LEDs on the Main Control Module, Functional
Modules, and Power Supply Modules indicate the status of the system.
MGC+ Control
Unit (CU)
R
MGC+
Power
In
Out
Figure 4-1: MGC+100 front panel
MGC+ Functional
Modules
Power
In
Out
Line 1
Line 2
Line 3
Line 4
Line 1
Line 5
Line 2
Line 6
Line 3
Line 7
Line 4
Line 8
Power
In
Out
