Table 5-1: Front Panel LEDs
Module Name
ReadiManager Power LED
IAM (left group)
Flash
Memory
LED
Shut Down
button
Compact
Flash slot
USB port
HD LED
Remove
Server LED
Power LED
Control Unit Power
(right group)
Flash
Memory
Major
Minor
Color Description
Yellow On. Not lit when OFF.
Red Read or write enable. Lit when
active.
NA Turn the ReadiManager ON or
OFF.
OFF - Closes all ReadiManager
processes and applications.
ON - Starts all ReadiManager
processes and applications.
NA Future use.
NA Future use.
Red Flashes when the Hardisk is
active.
Green When lit, you can remove the
ReadiManager server. This
button is lit when you press the
Shut Down button on the
ReadiManager.
Yellow On. Not lit when OFF.
Green Power supply normal.
Red Read or write enabled, is lit
when active
Red A major fault exists on the
MGC+ unit
Yellow A minor fault exists on the
MGC+ unit
