Chapter 5 - System Maintenance
5-8
Main Switch
AC Inlet
Figure 5-4: MGC+50 rear panel controls
The main power switch is used during installation, and replacement of fans,
main control module and power supply since the functional modules are hot
swappable. The switch includes an AC circuit breaker.
IO Card
DEBUG
LAN
VGA
MOUSE
LINE IN
KEYBOARD
COM1
COM2
ALARMS
Fan
