Polycom DOC2238A Hardware Installation Manual page 101

The module's front panel includes two, four or eight tri-color LEDs
(depending on the card's configuration). Depending on the states of the LEDs
inputs, the LED can be off, green, red or yellow. The red and yellow states
indicate alarms.
NET 2 NET 4 NET 8
Line 1
Line 2
Line 3
Line 4
Line 1 Line 5
Line 2 Line 6
Line 1 Line 3 Line 7
Line 2 Line 4
Line 8
Figure 4-11: 2/4/8 tri-color LED NET cards front panels
MGC+ Hardware and Installation Manual
4-21
