Animo Optivend Choco Service Enclosure page 41

6. Cold or hot water is
leaking from the bottom of
the machine.
7. Water is dripping out of
the drink spigot.
8. Mixing house leak
9. No ingredient come out
of the canister outlet. (gear
motot turns normally).
10. No ingredients dosed.
Mixer motor is not working.
11. Mixer motor does not
stop working.
12. Lumps in the ingredient
canister outlet.
13. Drink drips out of the
ventilation opening (bottom
of the machine).
01/2007 (rev. 6) V2.0
The electrodes are dirty.
The magnetic valve does not close.
The main controls are faulty.
The hose leaks.
The hot water valve does not close
properly.
O-ring in green fastening ring is
dirty, defective or has disappeared.
Gear motor ax does not drive the
canister worm. Gear motor ax is
damaged or canister is wrong
positioned.
The dosing motor or mixer motor
are broken.
24 Vdc power supply unit is not
supplying voltage.
Wire tree faulty.
Relay on the main controls remains
switched on. Output defective.
The ventilator does not work.
The mixer beakers or their outlets
are blocked.
41
Check the electrodes. Clean the
electrodes.
Switch the machine off. Replace
the magnetic valve if it does not
close.
Test the controls. Replace the I/O
control (#).
Replace the hose.
Initiate the cleaning program or
replace the valve if necessary.
De-scale the boiler and magnetic
valves. Follow the de-scaling
instructions (service manual).
Check the O-ring seal. Replace
the green fastening ring if
necessary.
Replace gear motor ax or
reposition canister.
Check the voltage (DC) to the
motor during dosing or mixing. If
there is voltage, the motor is
defective. Replace the motor.
Check the fuse and power supply.
Test the connection with the aid of
the circuit diagram. Repair any
faulty connections.
Replace the main controls.
Measure the voltage (DC) on the
ventilator during drink preparation.
If there is power, the ventilator is
defective. Replace the ventilator.
No voltage connector 11 main
controls. Replace the controls.
Remove the mixers and drain
hoses. Thoroughly clean the
mixers and hoses.
service enclosure
