1. Max./min. levelprobes
2. Hot water valves
3. Temperature sensor
4. Heating element
5. Inlet valve
6. Gear moters
7. Ingredient holders
8. Outlet
9. Hot water connection
10. Evaparation extractor
11. Mixer housing
12. Hot water outlet /
Drink outlet
13. Mixer impellor
14. Fastning ring
15. Mixer motor
16. Holder tableau
17. Evaparation box
18. Ventilator
19. Drip tray
Fig. 1
service enclosure
4
01/2007 (rev. 6) V2.0
