2.2.3 Additional information operator-/ service menu items

Operator menu
1.0 Free vend
1.1 Time
1.2 Switching times
1.3 PIN-code
1.4 Software
Service menu
2.0 Free vend
2.1 Recipe adjust.
2.2 Settings
2.2.0 Temperature
2.2.0.0 Temp. Boiler
2.2.0.1 Temp. Hysteresis
2.2.0.2 Temp. Min.
2.2.0.3 Temp. Stand-by
2.2.0.4 Pre Heat time.
01/2007 (rev. 6) V2.0
Select paid dosing or free dosing.
Set the actual time here.
Set the times when the machine is to be activated here.
A PIN code is required to enter the service menu from the operator
menu:
•
Default value of this PIN is (button) 2-2-2-2-2
•
You can change the PIN code in service menu item (2.13
change PIN code)
From V1.1a read out software version
This item is the same as operator menu item 1.0
This is where you can adjust all the parameters for every product
(button) if necessary. This sub-menu is so complex that a separate
chapter is devoted to this item. See chapter 3 Receipt settings
Select the desired boiler temperature here. Recommended
temperature for instant products is 85 °C.
Select the boiler temperature from where the boiler must warm up
(again).
Select the minimum boiler temperature from where the dosing will be
blocked. Display reports: F2 Heating.
Select the boiler temperature in stand-by mode.
To ensure an optimum boiler temperature, the heater will be switched
on when the inlet valve is activated. Enter the time lapse (sec.) for
which the heater must remain active after the inlet valve has been
closed. See arrow.
19
Inlet valve
heating
