5.1.2 Power supply
The 24 Vdc power supply (fig. 13) consists of a 24
Vdc – 65 W linked power supply unit and can be
accessed by removing the rear wall. The power
supply is located against the back of the main
controls.
service enclosure
Output
24Vdc / 65W
Input
85-265Vac
32
Fig. 13
01/2007 (rev. 6) V2.0
