9. Put the plug back in the socket and switch the
machine back on. The reservoir will now heat
up. Place the measuring cup under the outlet
(fig. 8-2) and activate the cleaning program at
least 3x (fig.8-1) so that the acid solution is
discharged from the water reservoir via the
valves. Don't forget to empty the measuring
cup!
10. Switch off the machine and allow the reservoir
to empty completely via the drain hose (fig.6-2).
11. Switch the machine back on. The reservoir will
refill with clean water. Repeat point 10 once
more to rinse any remaining acid out of the
water reservoir.
12. Switch the machine back on. The reservoir will
refill with clean water. Allow the water reservoir
to heat up.
13. Place the measuring cup under the outlet (fig.
8-2) and activate the cleaning program (fig. 8-
1) at least 3 x so that the valves and pipelines
are rinsed clean. Don't forget to empty the
measuring cup!
14. Repeat the above descaling procedure if there
are still lime deposits in the reservoir.
15. Replace the lid on the reservoir and replace the
rear partition.
16. Delete the service moment counter in the
service menu.
17. The machine is now ready for use.

4.3 Cleaning the evaporation system

1. After removing the canister plateau (fig. 9-1), the
evaporation box (fig. 9-2) can be cleaned easily.
2. The ventilation hose (fig. 9-3) and ventilator (fig.
9-4) are easy to remove through the right side
wall.
01/2007 (rev. 6) V2.0
3X
29
1
2
Fig. 8
1
2
3
4
Fig. 9
