Fawa Test - tecan M1000 Operating Manual Addendum

FaWa Test

36
19 The operator is now prompted Test Result: Passed or Test Result: Failed.
20 If Cancel was selected due to the door lock not functioning, then the Door
Lock Test fails. Close the door completely and repeat the Door Lock Test. If
the Door Lock Test fails again, contact your local Abbott representative.
21 Select <OK> from the Access Status Options Process prompt.
22 Select <OK> from the Access/Status Panel to return to the Setup & Service
main menu.
The Fast Wash Pump (FaWa) is used to pump a large amount of liquid at high
speed through the system, usually to flush the liquid system and remove any air
bubbles.
Test Sequence
The Fast Wash Pump test performs the following procedure to test the throughput
of the pump through the tips of DiTi adapters.
The tubes are prefilled, using the dilutors.
The level of the prefill is measured, using liquid detection.
The DiTis are removed.
The tubes are filled, using the Fast Wash Pump.
The DiTis are picked up.
The height increase of liquid is measured, using liquid detection.
The height increase is checked and must be within the expected minimum
throughput value.
1 Start the GENESIS Setup & Service software by clicking on the
TECAN icon.
2 From the GENESIS Setup & Service main screen, select Liquid System
from the menu bar.
m1000™ Operating Manual Addendum, 392813, en, V1.1
