tecan M1000 Operating Manual Addendum page 35

Selection
Flush
Flush tips once sequentially
The operator is prompted Do you want to
move LiHa above Washstation?
m1000™ Operating Manual Addendum, 392813, en, V1.1
5 Complete the following fields:
Field
Grid
Position
Use Fast Wash Pump
6 Close the Safety door.
7 Select one of the following functions:
8 Observe the dilutors for movement and leaks
– If the dilutors are leaking, check the plunger screw and syringe screw for
tightness. Also check the valve connections for tightness. Refer to the
m1000™ Operating Manual, Section 7.3.2.
– Change the syringes and/or 3-way valve. Refer to the m1000™ Operating
Manual, Section 7.5.
– Repeat the Dilutor tool.
– If the leaks continue, notify your local Abbott representative.
9 Select Print to print the report. Select <OK> to exit.
Selection
18
Waste
Function
Initializes all 8 dilutors at one time.
Initializes the dilutor one by one.
Select Yes.
31
