1. Access to the Web Configuration
Attention! The cellular router will not operate unless the cellular carrier has been cor-
rectly configured and the account activated and provisioned for data communications.
For UMTS and LTE carriers, a SIM card must be inserted into the router. Do not insert
the SIM card when the router is powered up.
You can monitor the status, configuration and administration of the router via the Web
interface. To access the router over the web interface, enter http://xxx.xxx.xxx.xxx into the
URL for the browser where xxx.xxx.xxx.xxx is the router IP address. The router's default IP
address is 192.168.1.1. The default username is root and the default password is root.
When you successfully enter login information on the login page, web interface will be
displayed. The left side of the web interface displays the menu. You will find links for the
Status, Configuration, Customization and Administration of the router.
Name and Location displays the router's name, location and SNMP configuration (see
3.17). These fields are user-defined for each router.
Figure 1: Example of the Web Configuration
2

1. ACCESS TO THE WEB CONF.
