2. Status

2.1 General Status

You can access a summary of basic router information and its activities by opening the
General page. This page is the default dialog displayed when you login to the device. Infor-
mation is divided into several sections, based upon the type of router activity or the properties
area: Mobile Connection, Primary LAN, Peripherals Ports and System Information. If your
router is equipped with WIFI expansion port, there is also WIFI section.

2.1.1 Mobile Connection

Item
SIM Card
Interface
Flags
IP Address
MTU
Rx Data
Rx Packets
Rx Errors
Rx Dropped
Rx Overruns
Tx Data
Tx Packets
Tx Errors
Tx Dropped
Tx Overruns
Uptime
Description
Identification of the SIM card (Primary or Secondary)
Defines the interface
Displays network interface flags
IP address of the interface
Maximum packet size that the equipment is able to transmit
Total number of received bytes
Received packets
Erroneous received packets
Dropped received packets
Lost received packets because of overload
Total number of sent bytes
Sent packets
Erroneous sent packets
Dropped sent packets
Lost sent packets because of overload
Indicates how long the connection to the cellular network has
been established
Table 1: Mobile Connection
