- Page 1 EKI-2525M Industrial 5-port Unmanaged Ethernet switch with 1-port 100FX EKI-2526M/S Industrial 5-port Unmanaged Ethernet switch with 2-port 100FX User Manual...
- Page 2 The documentation and the software included with this product are copyrighted 2007 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.
- Page 3 Because of Advantech s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
- Page 4 Step 2. Contact your distributor, sales representative, or Advantech’s customer service center for technical support if you need additional assistance. Please have the following information ready before you call: - Product name and serial number...
- Page 5 Safety Instructions 1. Read these safety instructions carefully. 2. Keep this User' s Manual for later reference. 3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning. 4.
- Page 6 Safety Precaution - Static Electricity Follow these simple precautions to protect yourself from harm and the products from damage. 1. To avoid electrical shock, always disconnect the power from your PC chassis before you work on it. Don' t touch any components on the CPU card or other cards while the PC is 2.
-
Page 7: Table Of Contents
Contents Chapter 1 Overview ........... 2 1.1 Introduction ............2 1.1.1 High-Speed Transmissions ....... 2 1.1.2 Dual Power Input ........2 1.1.3 Flexible Mounting........2 1.1.4 Advanced Protection......... 2 1.1.5 Wide Operating Temperature....2 1.1.6 Easy Troubleshooting ....... 2 1.2 Features............. 3 1.3 Specification ............ - Page 8 EKI-2525M & 2526M & 2526S User Manual.doc viii...
-
Page 9: Chapter 1 Overview
Overview Sections include: Introduction Features Specifications Packing List Safety Precaution Chapter1... -
Page 10: Introduction
Chapter 1 Overview 1.1 Introduction The EKI-2525M/2526M is a cost-effective solution and meets the high reliability requirements demanded by industrial applications. 1.1.1 High-Speed Transmissions The EKI-2525M/2526M is an industrial switch which provides you with one (EKI-2525M) or two (EKI-2526M) fiber port for your fiber optic cable to make a long-distance connection. -
Page 11: Features
1.2 Features • Provides 4 x 10/100TX + 1 x 100FX (EKI-2525M) or 4 x 10/100TX + 2 x 100FX (EKI-2526M) Mbps Ethernet ports with RJ-45 connector • Provides 2K (wide operating temp. model) or 1K (standard model) MAC address table •... -
Page 12: Specification
1.3 Specification Communications Compatibility IEEE 802.3, 802.3u, 802.3x 10/100Base-TX, 100Base-FX Transmission Distance Multi-Mode Fiber: 2KM ‡ ‡ 62.5/125 m) (50/125 UTP/STP up to 100 meters Transmission Speed Up to 100 Mbps Broadcast Storm Rate Limit 200pps (100M)/20pps (10M) Interface Connectors 4 x RJ-45 1 x SC type 100M fiber (EKI-2525M) 2 x SC type 100M fiber (EKI-2526M) - Page 13 Power Reverse Environment Operating Temperature -40~75 ‡ : ‡ » ł ‡ ł œ ‡ ł ł ł ‡ ł … -10~60 ‡ : ‡ » ‡ ł ł ł ‡ ł … Operating Humidity 5%~95% (non-condensing) Storage Temperature -40~85 ‡ : Certifications Safety UL, 60950-1, CAN/CSA-C22.2 No.60950...
-
Page 14: Packing List
1.4 Packing List • 1 x EKI-2525M or 1 x EKI-2526M Industrial Ethernet Switch • 1 x eAutomation Industrial Communication CD-ROM with software, and User manual • 2 x Wall Mounting Bracket and Screws • 1 x DIN-rail Mounting Bracket and Screws •... -
Page 15: Chapter 2 Installation
Installation Sections include: LED Indicators Dimensions Mounting Network Connection Power Connection Chapter2... - Page 16 Chapter 2 Installation In this chapter, you will be given an overview of the EKI-2525M/2526M hardware installation procedures. 2.1 LED Indicators There are few LEDs display the power status and network status located on the front panel of EKI-2525M/2526M, each of them has its own specific meaning as below table. Table 2.1: EKI-2525M/2526M LED Definition Color Description...
-
Page 17: Dimensions (Units: Mm)
2.2 Dimensions (units: mm) Figure 2.1: Front View of EKI-2525M/2526M Chapter2... - Page 18 Figure 2.2: Side View of EKI-2525M/2526M EKI-2525M & 2526M & 2526S User Manual.doc...
- Page 19 Figure 2.3: Rear View of EKI-2525M/2526M Chapter2...
- Page 20 Please refer to page 17 for pin assignment of power connector. Figure 2.4: Top View of EKI-2525M/2526M EKI-2525M & 2526M & 2526S User Manual.doc...
-
Page 21: Mounting
2.3 Mounting The EKI-2525M/2526M supports two mounting methods: DIN-rail & Wall. 2.3.1 Wall mounting EKI-2525M/2526M can be wall-mounted by using the included mounting kit. Then, hang on the EKI-2525M/2526M to the nails on the wall. First, use the screws included in the package to combine the EKI-2525M/2526M and metal mounting kit. -
Page 22: Din-Rail Mounting
2.3.2 DIN-rail Mounting You can also mount EKI-2525M/2526M on a standard DIN-rail by below steps. The DIN-rail kit is screwed on the industrial switch when out of factory. If the DIN-rail kit is not screwed on the industrial switch, please screw the DIN-rail kit on the switch first. First, hang the EKI-2525M/2526M to the DIN-rail with angle of inclination. - Page 23 Then, let the device down straight to slide over the rail smoothly. See Figure 2.7 Figure 2.7: Installation to DIN-rail Step 2 Chapter2...
-
Page 24: Network Connection
2.4 Network Connection The EKI-2525M or EKI-2526M has the SC type fiber port in multi mode (2Km). When you connect the fiber port to another one, please follow the below figure to connect it. Wrong connection will not allow the port to work normally. Figure 2.8: Pin Assignment of the Power Connector Attention This is a Class 1 Laser/LED product. -
Page 25: Power Connection
2.5 Power Connection The EKI-2525M/2526M supports dual +12 ~ 48 V power inputs and power-fail relay output. Figure 2.9: Pin Assignment of the Power Connector You can connect an alarm indicator, buzzer or other signaling equipment through the relay output. The relay opens if power input 1 or 2 fails ( “Open” means if you connect relay output with an LED, the light would be off). - Page 26 EKI-2525M & 2526M & 2526S User Manual.doc...
-
Page 27: Chapter 3 Troubleshooting
Troubleshooting Chapter2... - Page 28 Chapter 3 Troubleshooting Power Input Verify that is using the right power cord/adapter (+12~48 V ), please don’t use the power adaptor with DC output voltage higher than 48V, or it will burn this converter down. Cable Select the proper UTP cable to construct user network. Please check that is using the right cable.
-
Page 29: Appendix A Pin Assignment & Wiring
Pin Assignment & Wiring Chapter2... - Page 30 Appendix A Pin Assignment & Wiring It is suggested to adopt ELA/TIA as the wiring of the RJ-45. Figure A.1: RJ-45 Pin Assignment Figure A.2: EIA/TIA-568B Figure A.2: EIA/TIA-568A EKI-2525M & 2526M & 2526S User Manual.doc...
