Chapter 4: Jumpers and Connectors for VMC 3000 Series

USB Connector

Connector size: 1x5 5-pin header
Connector location: J1
5 1
Pin Definition
1 USB0/1_FP
2 USB_0N_L
3 USB_0P_L
4 USB_GND
Copyright © 2012 NEXCOM International Co., Ltd. All rights reserved
Pin Definition
5 CH_GND
MH1 GND
MH2 GND

Audio Connector

Connector size: 1x6 6-pin header
Connector location: J2
1 6
Pin Definition
1 FRONT_L_F
2 FRONT_JD
3 FRONT_R_F
4 MIC_JD_F
55
Pin Definition
5 MIC_JD
6 AGND
MH1 AGND
MH2 AGND
