Chapter 9: PenMount Gesture AP for Windows
a. Enable/disable Check Box. Select/deselect the box to enable/disable Pen-
Mount Gestures.
b. General Setting Box
b-1. Sensing Time - Move the slider to adjust PenMount Gestures Sensing
Time between 200 ms (0.2 sec) and 2500 (2.5 sec). The shorter the sensing
time is configured, the faster the gesture has to be done.
Sensitivity – Move the slider to adjust how sensitive you want your finger
b-2.
stroke on the touchsceen to be sensed.
c Gesture Settings Group Box. This group box allows you to individually
configure each gesture.
d Gesture Select Button. Press this button to select the specific gesture you
are going to configure. When the gesture icon turns to blue, it is enabled.
When it is gray, it is disabled. See the following for details.
Disable Button. When this button is selected, the gesture is disabled.
d-1.
d-2. Hot-key Configure Button. Configure the hot-keystrokes for specific
gesture. The hot-key can include up to 5 keystrokes. When that gesture is
sensed, the configured keystrokes will be reported.
d-3. Application Invoke Button. Configure to invoke a specific application with
particular gesture. So that when the gesture is sensed, the specific applica-
tion will run.
Action Configure Button. Configure to make use of
d-4.
PenMount Gesture AP's built-in shortcuts. So that
when a particular gesture is sensed, a specific action will
be taken. PenMount Gesture AP have the following
shortcuts built in:
Note: For Disable touch function, after touch function is disabled, the
mouse-pointer won't move following your finger sliding on the
touchscreen and your finger tapping won't trigger any action,
however, gestures will still be sensed.
(If you select Disable touch function, the curser will not react
to finger movement on the touch screen and the tapping
will not trigger any program action. However, the gesture
recognition is still functioning.)
Copyright © 2012 NEXCOM International Co., Ltd. All rights reserved
9.3 PenMount Gestures' Default Values
in Windows XP
Page Up
Backward
(Left Arrow)
Copy
(Ctrl + C)
Undo
(Ctrl + Z)
Zoom in
([Pad] +)
Rotate Counter Clockwise
(Ctrl + L)
Open On-Screen Keyboard
(Execute OSK.EXE)
Close Program
(Alt + F4)
117
Page Down
Forward
(Right Arrow)
Paste
(Ctrl + V)
Delete
Zoom out
([Pad] -)
Rotate Clockwise
(Ctrl + K)
Save Document
(Ctrl + S)
VMC 3000/4000 Series User Manual
