Appendix H: CAN Module Setup and Command
AT Command Summary
@1 AT@1: Display version information
Setting RS232 baud rate. xy is baud rate parameter.
ATBR09: 9600
ATBR19: 19200
BRxy
ATBR38: 38400
ATBR57: 57600
ATBR99: 115200
ATE0: echo off(Default)
Eh
ATE1; echo on
T ATT: Terminate sending. To use ATS will continue it.
ATI : Request vehicle ID, the length is variable.
1.) J1708:
Output format: ASCII code
Byte 0:0x2A
Byte 1: Vehicle ID byte 1
Byte 2: Vehicle ID byte 2
Byte N:Vehicle ID byte N
Byte N+1: Check Sum=Byte 1+Byte2+.......+Byte N
Byte N+2:0x0D
Byte N+3:0x0A
I
N: Max 20
2.)J1939
Byte 0:0x2A
Byte 1: Vehicle ID byte 1
Byte 2: Vehicle ID byte 2
Byte N:Vehicle ID byte N
Byte N+1: Check Sun= Byte1+Byte2 +.....ByteN
Byte N+1:0x0D
Byte N+2:0x0A
N: Max 35
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
PA ATPA: Print data by ASCII CODE format
ATR: Clear protocol and distance (D1 ,D2)memory, the ATR
PH command clear current protocol then continue learning next new
protocol.
ATRJ: Request J1939 FMS High Resolution Total Vehicle Distance
RJ
#33~#36
RH ATRH: Request Hino Truck Total vehicle distance (#33~#36)
ATS: Continue auto-send data every 100~200ms. To use ATT
S
will terminal it.
ATSS: Auto- send Simple Data every 100~200 ms.
SS
Refer to Simple Data format Protocol
ATSP: Auto-send Packaging Messages every 100~200 ms.
SP
Refer to Packaging Messages protocol.
ATSR: Auto-send J1939/J1708 Raw Data, Refer to Raw Data
SR
Protocol.
ATX: Request to send data of alternate, data format as
ATS/ATSP command.
For J1939 protocol:
X Packing1→Packing2→Packing 3→Packing4→Packing5→
Packing6→Packing1
For J1708 protocol:
Packing1→Packing2→Packing 3→Packing4→Packing5→ Packing1
AT#xy: The command will print designated data by ASCII code.
"xy" is data address, it is decimal.
#xy J1708: 00~53
J1939: 00~99.
EX: AT#01 , to get speed high byte.
