Chapter 1: Product Introduction

Hardware Specifications

VMC 3000/3001 and VMC 4000/4001/4011

General
• Cooling System: fanless
• Enclosure: die-cast aluminum
• Mounting: support VESA 75/100, panel and stand mounting
• Three SMA type antenna connectors of BT/ Wi-Fi / WWAN
• Power Input: 9~36VDC input with Ignition
• Power Consumption: 26W typical
• Ingress Protection: IP65
• Dimension:
VMC 3000/3001: 290mm (W) x 230mm (H) x 68mm (D)
(11.4" x 9" x 2.7")
VMC 4000/4001: 340mm (W) x 262mm (H) x 75.1mm (D)
(13.3" x 10.3" x 2.9")
• Weight:
VMC 3000/3001: 3kg, 6.61Lb
VMC 4000/4001: 3.5kg, 7.72Lb
LCD Panel
LCD Panel for VMC 3000/3001
• 10.4-inch TFT LCD panel with LED backlight
• 1024 x 768 pixels (XGA)
• Brightness: 400 cd/m² (typical)
• Optional high brightness for sunlight-readable with 1200cd/m
• Contrast ratio: 500:1 (typical)
Copyright © 2012 NEXCOM International Co., Ltd. All rights reserved
LCD Panel for VMC 4000/4001/4011
• 12.1-inch TFT LCD panel with LED backlight
• 1024 x 768 pixels (XGA)
• Brightness: 600 cd/m² (typical)
• Optional high brightness for sunlight-readable with 1300cd/m
(VMC 4011)
• Contrast ratio: 700:1 (typical)
Touch Screen Sensor
• 5-wire resistant touch
• Anti-glare coating surface
• Transmission rate: 81 ± 3%
CPU & Chipset
• Intel Atom™ D2550 1.86GHz
®
• Intel ICH10R
®
Memory
• One 204-pin DDR3 1333MHz SO-DIMM slot (up to 4GB)
Expandable Storage
• 1x CFast
• 1x 2.5" SATA SSD bay
Expansion
2 (typ.)
• 1x Mini-PCIe socket (PCIe + USB) for WLAN option
• 1x Mini-PCIe socket (USB) x 1 for WWAN option
• 1x CAN Bus module with J1939 for option
3
(typ.)
2
